01 / 09 · THE PARTS

Send a rescue signal.

One press lights a beacon, starts a scan, and changes what the story knows.

Build it with Otherwhere OS. We’ll go from loose parts to a complete scenario, with the configuration beside the thing it controls.

• 01 Raspberry Pi with a 40-pin header, power supply, and storage
• 02 Two momentary buttons: action and push-to-talk
• 03 An LED, a 1 kΩ resistor, breadboard, and jumper wires
• 04 A supported microphone and powered speaker

This guide uses the reference board, orion.console@3. The wiring is shared by both adventures. Changing the physical layout means defining your own board.

02 / 09 · WIRE IT

One connection at a time.

Disconnect the Pi’s power before wiring. Choose a part to see its connection and the matching board configuration.

components:
  primary_button:
    type: orion.momentary_button@1
    config:
      pin: 16
      active_low: true
      debounce_ms: 40

GPIO signals are 3.3 V. Keep 5 V away from these connections, and keep the resistor in series with the LED. Check your Pi’s header orientation ↗

03 / 09 · NAME IT

Give the parts useful names.

The board owns the pins. The scenario asks for a button, a light, a speaker, and a way to talk. That is what lets the same wiring become a different machine.

capabilities:
  primary_action: primary_button
  push_to_talk: talk_button
  status_indicator: alert_light
  main_audio: speaker
  microphone: microphone

A button has no permanent sound or story role. Adding another supported button usually means adding a component and binding. New hardware primitives may need a driver.

04 / 09 · THE STORY

Give the signal a reason.

Write who needs help and what the player can choose. Turning on a beacon is a fact. Someone receiving it is another part of the story.

characters:
  orion:
    name: Commander Orion
    personality: Calm, curious, and encouraging under pressure.
    prompt: You coordinate a friendly space rescue. Let the child choose who to help
      and how to explore.
    voice: orion_voice
    initial_presence: rescue_bridge

Start from the complete download, then change the character, rules, and starting facts together. Give your version its own scenario identity. Published versions are immutable.

05 / 09 · A PRESS

One press. Three things.

The button turns the lamp on, starts a named scan, and sends beacon_requested. A seven-second guard keeps repeat presses from starting another sequence.

- id: activate_beacon
  on: primary_action.pressed
  when:
    - { path: state.ready, op: eq, value: true }
  actions:
    - state.set: { path: ready, value: false }
    - light.set: { target: status_indicator, value: true }
    - sound.play: { asset: rescue_scan, key: scan }
    - timer.start: { timer: cooldown, delay_ms: 7000 }
    - server.emit: { event: beacon_requested }

The sounds are included in the download: verified prototype cues from the existing inventory. An asset alias chooses audio; it does not generate it.

06 / 09 · A RESPONSE

Remember that you called.

The server handles beacon_requested with two explicit effects: remember that the beacon is active, and publish its lamp state. The scan’s completion plays the confirmation chirp.

- id: scan_finished
  on: sound.completed
  when:
    - { path: event.key, op: eq, value: scan }
  actions:
    - sound.play: { asset: beacon_chirp, key: confirmation }

The light reacts locally right away. The server’s accepted effect makes the fact durable. Beacon active does not mean explorers rescued.

07 / 09 · RECOVERY

Pick up where you left off.

On reconnect, restore the saved beacon value with an absolute light command. Repeating it is harmless. Reopen temporary controls without replaying the scan or confirmation.

- id: beacon_restored
  on: server.beacon_sync
  actions:
    - light.set: { target: status_indicator, value_from: event.enabled }

routes:
  - id: capture_begin
    on: push_to_talk.pressed
    actions:
      - timer.cancel:
          timer: cooldown
      - state.set:
          path: ready
          value: true
      - capture.begin: {}
  - id: capture_stop
    on: push_to_talk.released
    actions:
      - capture.stop: {}

Local cues yield to narration and capture. Keep the completion, timeout, reconnect, and talk routes together when you adapt the example.

08 / 09 · TRY IT LOCALLY

Run the actual sequence.

Download the whole build: board, complete scenario, audio, catalog, and interaction trace. Extract the builds folder into your supplied pi-exp checkout.

Use Bun 1.4.0, Python 3.12, and uv 0.12.0. The prototype runtime comes with the supplied checkout; this download contains the build files. Run these commands from the checkout root.

bun --no-env-file tools/install-typescript-dependencies.ts
uv sync --project apps/device-agent --frozen --all-groups

The exercise builds the package, verifies the audio, and runs the real reactor with fake hardware. Read each step’s commands, local state, and server intents. Completing a fake sound is explicit; advancing time only drives timers.

09 / 09 · YOUR PI

Put it on your build.

With your Pi enrolled against the matching board, upload the audio, publish the scenario, and build its package. Otherwhere OS downloads and verifies the package before activating it.

This prototype uses the supplied installation and enrollment workflow, plus a configured server and authorized admin CLI. Set up and enroll your Pi → Keep credentials in your local runtime file.

bun --env-file=.env apps/admin-cli/src/main.ts asset upload builds/rescue/assets/audio/rescue_scan.wav --media-type audio/wav --kind PACKAGE_ASSET --json
bun --env-file=.env apps/admin-cli/src/main.ts asset upload builds/rescue/assets/audio/beacon_chirp.wav --media-type audio/wav --kind PACKAGE_ASSET --json

Use the actual package UUID returned by the build for PACKAGE_ID, and your enrolled Pi’s UUID for DEVICE_ID. Confirm orion.console@3 is published and matches that device. If you changed the layout or story, publish the new board/scenario identity and use those references instead.
